78 Voilà

Sliding aluminum fly screen side-scrolling with gray pleated mesh.

The flush-mounted installation includes a 78 mm spacer that houses both the flyscreen and the guide for the shutter. It comes standard with a black pleated mesh, but you can also request a gray pleated one. The bottom guide has a height of only 3 mm. Also, depending on your design, you can choose single or double shutter model, with central or asymmetrical handle, and magnetic closure.

Dimensions

Spacer 78, front roller box, roller box and handle (dimensions in mm)

Spacer 78, front roller box and roller box (dimensions in mm)

Handle and catenary dimensions (dimensions in mm)

Spacer 78, front end-side, end-side and bottom guide (dimensions in mm)

Spacer 78, front end-side, handle and catenary (dimensions in mm)

Spacer 78 and top guide (Spacer 50 + DIVA top guide) (dimensions in mm)

Sheeting and measures

Towels	Cod.	Description	MIN	MAX
Towels	Cod.	Description	MIN	MAX		PGN	Black Pleated Mesh	Altezza maggiore della base di 150 mm	1800x3200
	PGR	Grey Pleated Mesh	Altezza maggiore della base di 150 mm	1800x3200

Towels	Cod.	Description	MAX
Towels	Cod.	Description	MAX		PGN	Black Pleated Mesh	3600x3200
	PGR	Grey Pleated Mesh	3600x3200

Colours

D3R

Rough Shot Cherry*

Accessories

Black

* while stocks last

Known colors

The colours listed below are available for this model while stocks last:

9010 Glossy White
1013 Glossy Ivory
8017 Glossy Brown
Painted Silver
Painted Bronze
9010 Rough White
1013 Rough Ivory
Rough Musk Brown
7001 Rough Grey
Dark Bronze
9005 Matt Black
Marble Grey
Marble Brown
Bright Renolit

If the colour is no longer available in stock, the order will be shipped within 15 working days from the date of order confirmation and processed with the corresponding colour price according to the specified finish.

If a colour not included in our colour chart is requested, the order will be shipped within 25 working days from the date of order confirmation and processed with the corresponding surcharges.
